Fix your dryer


Save at least $80

If your dryer breaks down, here's the first thing to know: You can solve most dryer troubles yourself.

There's no need to find a technician, schedule a service call or pay $80 to $200 for repairs.

The fixes we show in this article correct about 90 percent of dryer breakdowns. Most repairs take about an hour, but set aside extra time to locate replacement parts.

To find parts, check the yellow pages or search online for "appliance parts." Aside from basic tools like a socket set and screw-drivers, you may need a continuity tester or multimeter to diagnose the problem.

Dryer disassembly

[GRAPHIC OMITTED]

Most dryer repairs require some disassembly of the outer cabinet so you can get at the parts inside. If your dryer's lint filter is inside the front door (Figure A), disassemble it this way: First, remove the screws at each corner of the control panel. Flip the panel up and back to expose the screws in the top panel. Remove the screws, then pull the top toward you and lift it off. To open the bottom panel, release the spring catches by shoving a putty knife into the slot just above them. With the bottom panel open, you can remove the front panel by removing two screws at the top and two at the bottom.


If your filter slides into the top of the dryer, remove the screws alongside the filter slot. Using a putty knife, release the two spring catches located under the top panel at the front. Tilt the top panel up like a car hood and remove the screws that hold the front panel in place.

tip

The first step in any appliance repair is to make sure it's getting electricity. Unplugged cords and tripped breakers are a leading cause of appliance "breakdowns."

CAUTION

Don't get shocked! Unplug the dryer before you do any disassembly, diagnostic or repair work. On a gas dryer, also turn off the gas supply shutoff valve.

Dryer won't start

[GRAPHIC OMITTED]

If your dryer seems absolutely dead when you turn it on, chances are the door switch is bad or the plunger is broken or bent. Door switches wear out from normal use, but repeatedly slamming the door can speed up their demise. Start by checking the plunger located on the door. If it's missing or bent, replace it. If the plunger checks out, the next step is to remove the top cabinet panel to gain access to the door switch. See the disassembly instructions on p. 42.

Test the switch ($26) for continuity (see p. 42). If the switch is good, test the thermal fuse (see photo, p. 46) mounted on the blower housing. If you have a gas dryer with the lint filter in the door, access the thermal fuse by opening the bottom panel. If the filter slides into the top of the machine, remove the entire front panel. On an electric dryer, remove the rear service panel. If you don't get a continuity reading from the thermal fuse, do NOT simply replace it. A blown thermal fuse is a warning that you have other serious problems--either a malfunctioning thermostat or a clogged vent. Fix those before replacing the fuse ($20).

[GRAPHIC OMITTED]



Dryer thumps, rumbles or chirps

[GRAPHIC OMITTED]

The drum support rollers are worn. Replace all of them ($25; shown below). If the noise continues, replace the tensioner roller (p. 47). Since it takes longer to disassemble the machine than to actually replace the rollers and belts, we recommend replacing both of them at the same time--total parts cost is $45.


No heat

[GRAPHIC OMITTED]

If you have an electric or gas dryer that tumbles but won't heat, check the thermal fuse for continuity. If the thermal fuse checks out, move on to the radiant sensor if you have a gas dryer. It monitors the igniter and powers up the gas valve coils when the igniter reaches peak temperature. A bum sensor will stop the whole show. Test it for continuity (Photo 1) and replace it if it fails ($32). If the sensor is good, disconnect the electrical connector to the igniter and check it for continuity. Again, replace it if it fails the continuity test ($40). If both the radiant sensor and the igniter pass the test, replace the gas valve coils ($30 per set). To replace them, remove the retaining plate, unplug the sensors and pull them off the gas valve.

[GRAPHIC OMITTED]

If the thermal fuse on your electric dryer checks out, test the heater element for continuity. Replace the element ($55) if you don't get continuity (Photos 2 and 3).



[GRAPHIC OMITTED]

1 On a gas dryer, test the radiant sensor, igniter and thermal fuse by disconnecting the wires and checking for continuity. Replace them if they fail the continuity test.


2 Disconnect the wires to the heating element of an electric dryer and test it for continuity. Replace the element if you don't get a continuity reading.

[GRAPHIC OMITTED]



3 Replace the bad heating element on an electric dryer by unscrewing the retaining clip at the top of the heater box. Then pull out the box and remove the element retaining screw. Swap the elements and reinstall.

[GRAPHIC OMITTED]



Drum won't rotate, but the motor runs

You're in luck--it's only a broken belt ($20). Remove the front cabinet panel and lift the entire drum out of the cabinet. Now's the time to fire up your shop vacuum and suck out all the lint. Then spin the tensioner roller by hand to see if it runs smoothly and examine it for cracks. Replace the tensioner ($17) if it fails either test. Reinstall the drum and wrap the new belt around it (ribs facing the drum). Some tensioners are mounted behind the motor, so they're difficult to see from the front access panel. You'll have to do this by feel. Reach your hands around the blower housing and lift the tensioner up while you route the belt around the motor pulley.

Using a continuity tester

[GRAPHIC OMITTED]

Our photos show using a multimeter ($25) to diagnose trouble. But a continuity tester ($5) will also work for all the troubleshooting in this article. To use a continuity tester, simply attach the damp to one contact point and touch the probe to the other. If the light glows, you've got continuity. If not, you've got trouble.

thefamilyhandyman.com

More money-saving appliance repairs:

* To solve the most common fridge troubles, go to thefamilyhandyman.com/fridgefixes.

* Repair a gas or electric range. See how at thefamilyhandyman.com/rangefixes.

* See how to fix a leaking washing machine at thefamilyhandyman.com/leakywasher.

* Fix common dishwasher problems fast. See how at thefamilyhandyman.com/dishwasherfixes.

by Rick Muscoplat
